Vibration Monitors

Vibrations and their impact on both people and infrastructure have become increasingly important due to the adverse effects they can have on health and work activities, as well as the damage they can cause to structures. In the field of occupational health, there are tools available to measure the effects of vibrations on both the hand-arm and whole-body levels, even simultaneously. These tools are essential for monitoring workers’ exposure and ensuring they do not exceed recommended levels set by international standards. Today, there are also vibration dosimeters designed to monitor exposure during work without disrupting workers’ tasks. In addition, there are monitors to measure the level of vibrations that a structure is subjected to in accordance with international standards, helping to determine if activities such as mining blasting or construction can harm nearby structures or people. With the right equipment, the negative effects of vibrations can be prevented, ensuring the safety of workers and structures, and ensuring the proper functioning of industrial machinery through regular maintenance.

Brands in this category

FAQ

What is a vibration monitor?

A vibration monitor is an instrument that is used to measure and record the level and frequency of vibrations in a specific environment. It is commonly used to monitor the impact of vibrations on people, structures, and machinery in various fields such as occupational health, construction, and industrial operations. Vibration monitors are designed to measure and track the level of exposure to vibrations over time and determine if they exceed recommended levels set by international standards. The data collected by vibration monitors can be used to prevent negative health effects on workers, assess the impact of vibrations on structures and buildings, and ensure the proper functioning of industrial machinery.

What are the typical types of vibrations to be monitored?

Hand-arm vibration and whole-body vibration are two of the most common types of vibrations that should be monitored in different industries and fields.

Hand-arm vibration is the vibration that is transmitted from a tool or machine to the hand and arm of the operator. This type of vibration is commonly encountered in industries such as construction, manufacturing, and maintenance, where workers use hand-held power tools such as jackhammers, sanders, and grinders. Prolonged exposure to hand-arm vibration can lead to conditions such as hand-arm vibration syndrome (HAVS), which can cause damage to blood vessels, nerves, and joints in the hand and arm.

Whole-body vibration, on the other hand, is the vibration that is transmitted to the entire body of the worker, typically through the floor, seat, or platform on which they stand or sit. This type of vibration is commonly encountered in industries such as mining, transportation, and agriculture, where workers operate heavy machinery and vehicles. Prolonged exposure to whole-body vibration can lead to conditions such as lower back pain, spinal injury, and neck pain.

To prevent negative health effects from exposure to hand-arm and whole-body vibrations, it is important to monitor and control their levels in the workplace. Vibration monitors can provide accurate and reliable data on the level and frequency of these vibrations, which can be used to determine if they exceed recommended levels set by international standards.

How do vibration monitors measure exposure to workers?

Vibration monitors measure exposure to workers by detecting the level and frequency of vibrations in the environment. They can measure both hand-arm and whole-body vibrations, which can be harmful to workers if exposure exceeds recommended levels set by international standards. The data collected by vibration monitors is used to assess the exposure of workers over time and determine if they are exceeding the recommended levels, thereby allowing for necessary measures to be taken to prevent negative health effects. The information collected by vibration monitors can also be used to make improvements in work processes and equipment to reduce exposure to harmful vibrations.

What international standards are used to determine safe levels of vibration exposure?

International standards for safe levels of vibration exposure are typically set by organizations such as the International Organization for Standardization (ISO) and the International Commission on Occupational Health (ICOH). These standards take into account the type and duration of exposure, as well as the frequency and intensity of the vibrations. They provide guidelines for evaluating and controlling the risk of vibration-related health problems in workers, including hand-arm vibration syndrome (HAVS) and whole-body vibration (WBV) exposure. The most commonly used standards for hand-arm vibration include ISO 5349 and ISO 8041, while ISO 2631 and ISO 2631-1 are commonly used for whole-body vibration exposure. These standards provide a basis for employers to assess the risk of vibration exposure to workers and to implement controls to reduce the risk of harm.

How accurate is a vibration monitor?

The accuracy of a vibration monitor depends on several factors, including the quality of the instrument, the type of sensor used, the environment in which it is used, and the way in which the measurements are taken. In general, high-quality vibration monitors are designed to provide highly accurate measurements within a specified range of frequencies and amplitudes. The accuracy of the readings can be affected by factors such as the type of sensor used, the environment in which the measurements are taken (such as temperature, humidity, and electromagnetic interference), and the way in which the measurements are taken (such as the duration and frequency of the measurements).

To ensure accurate readings, it is important to use a vibration monitor that is appropriate for the specific application and to use it in accordance with the manufacturer’s recommendations. In some cases, it may also be necessary to calibrate the instrument regularly to maintain its accuracy.

What are the common sources of vibration in the workplace?

Common sources of vibration in the workplace include machinery and equipment such as power tools, engines, pumps, compressors, and conveyor systems. Other sources of vibration in the workplace can include transportation systems like trains and trucks, as well as construction activities such as blasting and pile-driving. Additionally, the physical environment itself can generate vibrations, such as earthquakes, wind and waves, and even the foot traffic of workers and equipment. To ensure the safety and well-being of workers, it is important to monitor and manage exposure to vibrations in the workplace.

Are vibration monitors capable of measuring vibrations in real-time?

Yes, some vibration monitors are capable of measuring vibrations in real-time. This allows for continuous monitoring of vibration levels and the ability to take immediate action if necessary to prevent any negative effects on workers, structures, or machinery. Real-time monitoring can also help to identify potential issues with machinery, allowing for preventative maintenance to be performed before the machinery fails.

How do vibration monitors help prevent negative effects on structures and buildings?

Vibration monitors help prevent negative effects on structures and buildings by measuring and tracking the level of vibrations that a structure is exposed to. The data collected by these monitors can be used to determine if the vibrations produced by various activities, such as construction, mining blasting, and industrial operations, are exceeding the recommended levels set by international standards. This information can then be used to assess the impact of these vibrations on nearby structures and buildings and to take appropriate measures to prevent any damage. By monitoring the level of vibrations, vibration monitors help ensure the structural integrity and stability of buildings and other structures, and can help prevent the need for costly repairs or renovations in the future.

Can vibration monitors help determine the maintenance needs of industrial machinery?

Yes, vibration monitors can help determine the maintenance needs of industrial machinery. By measuring and tracking the levels of vibrations emitted by machinery over time, vibration monitors can detect any changes or fluctuations in the vibration levels. This data can then be used to identify potential problems with the machinery and determine when maintenance is required. This can help prevent unscheduled downtime, prolong the lifespan of the machinery, and ensure the machinery is functioning properly.

What type of data can be gathered and analyzed with the use of vibration monitors?

Vibration monitors can gather and analyze a wide range of data related to the level and frequency of vibrations in a specific environment. This data can include information about the intensity and duration of vibrations, as well as their frequency spectrum and frequency distribution. Additionally, vibration monitors can also provide information about the effect of vibrations on workers, structures, and machinery, including hand-arm vibration and whole-body vibration exposure levels, and their compliance with international safety standards. The data collected by vibration monitors can be used to identify trends and patterns over time, and to inform decisions about vibration control measures, maintenance, and other risk management strategies.

What are the key factors to consider when selecting a vibration monitor?

When selecting a vibration monitor, there are several key factors to consider to ensure that the monitor is appropriate for the intended use and will provide accurate and reliable data. Some of these factors include:

  • It is crucial to clearly define the intended application and determine the necessary compliance with industry standards. This will ensure that the selected equipment is best suited for the specific needs and requirements of the application.
  • Type of vibration: Consider whether you need to monitor hand-arm or whole-body vibration, or both.
  • Measurement range: Determine the range of vibrations that need to be measured and ensure that the monitor has the appropriate measurement range.
  • Frequency range: Consider the frequency range of the vibrations that need to be measured and ensure that the monitor has the appropriate frequency response.
  • Data storage: Determine the amount of data storage required and ensure that the monitor has enough memory to store the data over the desired time period.
  • Data transfer: Consider how the data will be transferred from the monitor to a computer or other device for analysis and ensure that the monitor has the appropriate data transfer capabilities.
  • Power source: Consider the power source for the monitor and ensure that it is appropriate for the intended use, whether it be an internal battery, external power supply, or solar panel.
  • User interface: Consider the user interface of the monitor and ensure that it is intuitive and easy to use.
  • Cost: Consider the cost of the monitor and ensure that it is within your budget.
  • Manufacturer: Consider the reputation of the manufacturer and ensure that they are reputable and have a good track record of producing high-quality monitors.

By considering these factors, you can select a vibration monitor that is appropriate for your needs and will provide accurate and reliable data. At Inteccon, we offer a wide range of vibration monitors designed to meet the diverse needs of various industries.

Besides, when selecting a vibration monitor, it is important to consider the type of vibrations you will be measuring. If you are measuring human vibrations, you need to consider the frequency range of human vibrations and the type of instrumentation being used to measure them. Factors such as frequency response, accuracy, and ease of use should also be considered.

On the other hand, if you are measuring building vibrations, factors such as the size of the building, the type of structure, and the type of instrumentation being used to measure the vibrations should be considered. Other factors such as accuracy, frequency range, and ease of use should also be taken into account. It is important to choose a vibration monitor that is appropriate for the specific application and that meets the required measurement accuracy.

What are the most typical human vibrations?

Human vibrations refer to the mechanical shocks, movements, and other types of vibrations that are transmitted to the body through various sources, such as work tasks, transportation, and leisure activities. Some of the most common types of human vibrations include:

  • Hand-arm vibrations: Vibrations that are transmitted to the hands and arms through the use of hand-held power tools, such as jackhammers and chainsaws.
  • Whole-body vibrations: Vibrations that are transmitted to the entire body, often through exposure to vehicles, such as cars and trains, or work tasks that involve standing or sitting on vibrating surfaces.
  • Foot vibrations: Vibrations that are transmitted to the feet and legs through exposure to work tasks that involve standing or walking on vibrating surfaces, such as working in a noisy factory or operating heavy machinery.
  • Seat vibrations: Vibrations that are transmitted to the body through sitting on vibrating surfaces, such as in a car or on a motorcycle.

It is important to consider these types of human vibrations when selecting a vibration monitor, as different monitors may be better suited for measuring specific types of vibrations, and the type of vibrations being measured will impact the choice of your device.

What are the most typical building vibrations?

Building vibrations are typically caused by a variety of sources such as mechanical systems, traffic, earthquakes, wind, and construction activities. The most common types of building vibrations include:

  • HVAC (Heating, Ventilation, and Air Conditioning) system vibrations: These are caused by the operation of fans, pumps, and motors in HVAC systems, and can be transmitted through the building structure.
  • Traffic-induced vibrations: These are caused by passing vehicles, and can be particularly significant in buildings located near busy roads or highways.
  • Earthquake-induced vibrations: Earthquakes can cause significant ground motion, which can result in building vibrations.
  • Wind-induced vibrations: Wind can cause building vibrations by applying pressure to the building structure.
  • Construction-related vibrations: These are caused by activities such as pile driving, excavation, and demolition.

It is important to consider the type of building vibrations when selecting a vibration monitor, as different types of vibrations may require different measurement techniques and equipment. Our models are equipped with advanced features and technologies to accurately measure and track exposure to vibrations in real-time. Whether you need to monitor hand-arm or whole-body vibration levels, we have a solution that fits your needs. Our products are designed with user-friendly interfaces and easy-to-use software, making it simple to gather and analyze data. In addition, our models are built with durability and reliability in mind, ensuring accurate and consistent measurements over time.

Svantek Models for human vibrations:

SV 100A

The SV100A is a cutting-edge whole-body vibration exposure meter designed for easy and efficient measurement in accordance with ISO 2631-1. It features wireless Bluetooth communication, enabling real-time data preview on a smartphone or tablet through the Assistant Android app, which also sends alerts when set vibration limits are exceeded. The device automatically detects the operator in the workplace and adjusts its orientation and weighting filters accordingly. The SV100A has RMS and RMQ detectors for calculating daily exposure and stores results in an 8GB internal memory. The USB 2.0 interface enables fast data download and battery recharging. The device is also equipped with frequency analysis and time signal recording options, and is fully configurable with the Supervisor software for easy reporting. With its compact, lightweight, and robust design, the SV100A is the ideal choice for efficient and accurate whole-body vibration monitoring.

SV 103

The SV 103 is a personal hand-arm vibration exposure meter that meets the ISO 8041:2005 standard and is designed for measurements in accordance with the European Directive 2002/44/EC. This compact and lightweight device can be attached to the user’s arm and won’t interfere with their work activities. It features an OLED screen for easy viewing of results and information, and is powered by rechargeable batteries or via USB. With a large 8GB memory, real-time analysis, and time-domain signal recording capabilities, the SV 103 offers reliable and accurate measurement data. The instrument can be easily configured and managed using the Supervisor software, which also allows for daily vibration exposure recalculation.

SV 106A

The SV 106A Six-Channel Human Vibration Meter and Analyser is a compact, pocket-sized device that measures vibrations according to international standards, including ISO 8041:2005, ISO 2631-1,2&5, ISO 5349, and Directive 2002/44/EC. It features six channels for acceleration and two channels for static force measurements. The device is capable of simultaneous measurements with two triaxial accelerometers, and provides RMS, Peak, Peak-Peak, VDV, MTVV, A(8), and AEQ results with all required weighting filters.

The SV 106A can perform 1/1 or 1/3 octave real-time analysis, and features advanced time-history logging and time-domain signal recording. Results can be easily downloaded to a PC using the USB interface, and the device works with Svantek’s “Supervisor” software and SVAN PC++ analysis package. The SV 38V seat accelerometer makes whole-body vibration measurements easy, while the SV 105A or SV 150 triaxial accelerometers enable hand-arm vibration measurements. The device is lightweight, user-friendly, and easy to use with its color display.

Svantek Models for building vibrations:

SV 958A

The SVAN 958A is a unique four-channel instrument that offers simultaneous sound and vibration analysis with a measurement range of 20kHz. It is designed for class 1 noise measurements and tri-axial vibration assessments, and provides advanced analysis capabilities in real-time. The four input channels can be independently configured for sound or vibration detection, giving users a wide range of measurement options. The instrument has the ability to perform FFT, 1/1 or 1/3 octave, cross spectra, sound intensity, RT 60, and more. The results are stored in a 32 MB non-volatile internal memory or a USB memory stick and can be easily downloaded to a PC using the SvanPC++ software. The SVAN 958A is powered by four AA standard or rechargeable batteries, or an external DC power source or USB interface. The compact, lightweight design and robust case make it an exceptional instrument for various applications.

SV 974

The SVAN 974 is a versatile digital vibration level meter and analyzer that is ideal for general vibration measurements and machinery condition monitoring. Designed for use by consultants, maintenance services, and industrial R&D departments, the instrument offers parallel acceleration, velocity, and displacement measurements with three separate profiles. Each profile can be independently configured with different filters and RMS detector time constants, providing a wealth of results such as RMS, Peak, and Max.

The advanced time-history logging function records complete information about the measured signal, and the data can be easily transferred to a PC via the USB interface and SvanPC++ software. The SVAN 974 also offers real-time 1/1 or 1/3 octave analysis and FFT analysis, as well as RPM measurement with a Monarch laser tachometer. The instrument is powered by four AA standard or rechargeable batteries, and the compact and lightweight design makes it easy to use in any setting.
